Your Leading AB Cable and ADSS Accessories Supplier
Baoding Sihedan Electric Technology Co.,Ltd. is a hi-tech enterprise specialized in designing and producing strain clamp, suspension clamp, PG Clamp, IPC Clamp, stay rod, earth rod,crossarm etc electric Power fittings, silicon rubber insulators, glass insulators, Porcelain insulators, fuse cutout, Surge arresters, Switch gear, MCB etc. Our AB cable and ADSS accessories include Anchor clamp, OPGW tower bracket, Suspension clamps, IPC connector, Pre-insulated sleeve, Pre-insulated lug, End caps, etc., with many types and wide uses. In order to solve your technical problems more quickly, please call 0086-13968767426 or send email to info@dkline.net we will reply you in the first time.
Why Choose Us?
OEM & ODM Service
We especially have advantage on OEM and ODM of all electric Power fittings.
Advanced Facilities
We have specialized production workshops for machinery, forging, welding, stamping etc.
Global Market
Our Products are sold to USA, Malaysia, Bolivia, East Timor, England, Hong Kong, Camernoon, Kenya, Uganda etc.
Classification of AB Cable and ADSS Accessories
OPGW Tower Bracket
OPGW tower bracket products are hot-dip galvanized with good corrosion resistance, reasonable structure, strong and durable. Usually mounted on tension towers and rods.
Service Tension Clamp
The self supporting ABC cable anchor clamp used for round cable with cross section from 2(4)x10mm2, 2(4)x16mm2, and 2(4)x25 mm2 self supporting Aerial Bundled Cable with out neutral messenger. Its consists of a hot dip galvanized bail, Fiber glass reinforced plastic body and wedge insert with weather and UV resistant.
Insulation Piercing Connectors（JBC）
IPCs are similar to line taps used for overhead lines, enabling a branch connection to be made to an existing cable without stripping the insulation of the cable, and using a shear head bolt to ensure it is tightened to the correct torque. This is well established technology in some industries and prevalent in the distribution network but not generally used on the consumer's side of the installation.
Pre-insulated Sleeve MJPN
MJPTN is designed to connect the insulated cable in aerial distribution network. The sleeve is with full tension. its cap can prevent the water into the barrel.It is colored differently to distinguish the cable sizes. Marked with type,cable size,die size,inner cable length and number of crimping.
Pre-Insulated Lugs
The lug is composed of an aluminum barrel friction welded to an aluminium or copper palm. The insulation of the barrel is made with a black thermoplastic sealed with a flexible elastomer ring. A seal is also installed in, between the copper and the aluminium, in order to avoid galvanic corrosion. The crimping is made directly on the plastic part. They are water resistant.
Technical Parameters of AB Cable and ADSS Accessories
|
Type |
Applicable conductor range |
Bolt.No. (pcs) |
|
|
Main line section(mm2) |
Branch line section(mm2) |
||
|
JBC-0 |
25-70 |
6-35 |
1 |
|
JBC-1 |
35-70 |
6-35 |
1 |
|
JBC-2 |
35-150 |
35-150 |
1 |
|
JBC-3 |
50-240 |
50-240 |
2 |
|
CT1 |
25-70 |
6-35 |
1 |
|
CT2 |
25-95 |
6-25 |
1 |
|
DZ3 |
25-95 |
25-95 |
2 |
Installation Requirements of AB Cable and ADSS Accessories
Careful handling
AB Cable and ADSS Accessories should be handled with care to avoid kinks, twists, or damage to the insulation. Proper lifting and support mechanisms should be used to prevent excessive bending or stress on the cables.
Tension control
The tension applied during the stringing or pulling process should be controlled within the manufacturer's recommended limits. Excessive tension can lead to cable damage or elongation, while insufficient tension can result in sagging or inadequate clearance distances.
Alignment and sag
It is crucial to maintain proper alignment and sag between the cables. Sag is necessary to accommodate thermal expansion and contraction, as well as to prevent excessive strain on the cable during temperature variations. Sag values should be determined based on cable specifications and environmental conditions.
Clearance distances
Adequate clearance must be maintained between the cables and any obstacles such as trees, buildings, or other power lines. Clearances should comply with regulatory requirements and safety standards to prevent the risk of short circuits or physical damage.
Anchoring, Termination, and Strain Relief
Once the AB Cable and ADSS Accessoriess are strung or pulled into position, proper anchoring, termination, and strain relief techniques are essential for long-term performance and reliability.
Customizable Options
| MOQ | There are no MOQ limit in first order, and 100pcs in further. |
| Samples | We are providing the samples by free, but need pay for the freight charge. |
Usage of AB Cable and ADSS Accessories
Facilitated Installation: Because of the bundling of conductors on single cable, AB cable and ADSS accessoriess facilitate the installation process. There are no longer any requirements for individual separate conductors, which simplifies the construction and makes it less expensive by eliminating the need to string an excessive number of lines together.
Increase of Security: AB cable and ADSS accessoriess assist in improving security in power distribution systems because they are built with insulation. The insulation materials, aside from preventing electrical leakage, make accidental touching of charged areas, which in most cases renders unsafe both maintenance workers and the public, less likely.
Wider Range of Application: AB cable and ADSS accessoriess have reliable weather performance characteristics and can be used in windy, hot and high UV radiation environments. Cables have good strength and long service life, therefore, they are applicable in many fields, such as residential, commercial, and industrial.
Reduced Power Loss: Lifetime operational loss can be reduced to its absolute minimum via proper spacing techniques and using insulated conductors for construct AB cable and ADSS accessoriess. Such bundled design is good against electromagnetic interference and improves efficiency hence, making the electricity more reliable and efficient for distribution.
Versatile Use: With the ability: To support power distribution over long distances and difficult terrains Including inside cities and villages, the AB cable and ADSS accessoriess can be set up in Horizontal spans, vertical drops and even on streets crossings through various fittings on distribution networks that can be designed quite easily.
Economic Viable: Use of AB cable and ADSS accessoriess turn out to be economical owing to low installation and maintenance costs in comparison with a normal overhead line system. The enhancement of safety features, reduction of hardware needed and simplification of the installation procedures enables costs saving in general.
Packing
|
Qty. |
100pcs / carton |
|
Carton length |
475mm |
|
Carton width |
245mm |
|
Carton height |
325mm |
|
Gross weight |
15kg |
After-Sales Service
Give a clear answer to the user's complaints within 24 hours.
1
>>
If necessary, we send technicists to the user's site to solve the problem timely.
2
>>
Return visit at regular intervals.
3
>>
Establishing the user's record.
4
>>
Long warranty period, and whole life service and support.
5
>>
Providing the latest industrial information.
6
Payment Terms
|
1: |
We are accepting T/T and L/C payment terms. And FOB, CIF, CFR. |
|
2: |
Sample order: 100% payment before shipment. |
|
3: |
Bulk order: 50% deposit balance before shipment. |
FAQ
We're well-known as one of the leading ab cable and adss accessories manufacturers and suppliers in China. Welcome to buy high quality ab cable and adss accessories at low price from our factory. Contact us for more discount information.
