Lugs and Connectors

Your Leading Lugs and Connectors Supplier

Baoding Sihedan Electric Technology Co.,Ltd is a high-tech enterprise specializing in the design and production of Lugs and connectors. Lugs and connectors are devices used to terminate, splice, or connect cables and wires. There are several types of lugs and connectors, include h type connector, copper-aluminum connector, coupler, bimetallic lugs dtl-2, gtla bimetal lug, ot copper open nose terminal, etc. Each type has its own unique features and applications. In order to solve your technical problems more quickly, please call 0086-13968767426 or send email to info@dkline.net we will reply you in the first time.

First 12 3 Last

Why Choose Us?

OEM & ODM Service

We especially have advantage on OEM and ODM of all electric Power fittings.

Advanced Facilities

We have specialized production workshops for machinery, forging, welding, stamping etc.

Global Market

Our Products are sold to USA, Malaysia, Bolivia, East Timor, England, Hong Kong, Camernoon, Kenya, Uganda etc.

Classification of Lugs and Connectors

Connector

The H tap compression connector is a non-tension connector, it usually used in MV and LV overhead distribution line for non-tension splice, service drops, cable branch and grounding installation. The H tap connector suit for made from conductor-grade soft aluminium for connection combinations of Aluminium to Aluminium or Aluminium to Copper conductor.

Lugs

Terminal connectors are used to connect tap conductors to power equipment (transformers, circuit breakers, disconnect switches, etc.) or to wall substation bushings. Aluminum joints are also used to connect tap conductors to T-joints. Connectors include compression types.

Technical Parameters of Lugs and Connectors

Part No.		DH-1	DH-2	DH-3	DH-4	DH-5	DH-6
Main dimensions	L	40	48	60	50.5	50	90
	W	45	60	65	88	93	96
	H	17	22	22	32	32	32

Features of Lugs and Connectors

Lugs

● High Conductivity for Superior Performance
Our DTL-2 Cable Bimetallic Lug 63 features a unique combination of copper and aluminum, offering exceptional conductivity and minimal resistance. This ensures a reliable and stable connection, reducing the risk of overheating and enhancing the efficiency of your electrical systems.

● Robust and Durable Construction
Constructed to withstand harsh environments, the DTL-2 Cable Bimetallic Lug 63 is built with high-quality materials that resist corrosion and mechanical stress. This durability extends the lifespan of your connections, making it a cost-effective solution for long-term installations.

● Easy Installation and Versatile Application
The N.I.U. DTL-2 Cable Bimetallic Lug 63 is designed for easy installation, saving you time and effort during setup. Its versatile design makes it suitable for various electrical applications, from residential wiring to industrial power distribution.

Connectors

● Corrosion-resistant heavy-duty aluminum construction;

● Features A & B grooves for accommodating run and tap conductors;

● Bendable taps on each side secure the conductors when folded;

● Ribs are formable to provide a wide contact area;

● Connection area is prefilled with oxide inhibitor;

● Meets the required standards and temperature ratings.

Installation of Lugs and Connectors

Prepare the Cable

Begin by stripping the insulation from the end of the cable to expose the conductor. The length of the exposed conductor should match the depth of the lug's barrel.

Select the Appropriate Lug

Choose the correct type and size of lug for your application. Ensure that the lug is compatible with the conductor material and the electrical load.

Insert the Conductor

Insert the exposed conductor into the lug's barrel. Ensure that the conductor is fully inserted and that there are no stray strands outside the barrel.

Crimp or Tighten the Lug

If using a compression lug, use a crimping tool to compress the barrel onto the conductor. For mechanical lugs, tighten the set screw to secure the conductor in place.

Inspect the Connection

After installation, inspect the connection to ensure it is secure and that there are no visible gaps or loose strands. A secure connection is essential for reliable electrical performance.

Precautions for Using Lugs and Connectors: Temperature and Humidity

The environment in which the cable lug will be used is an important factor to consider when selecting the appropriate component for your electrical system. Temperature and humidity are key factors that can affect the performance and longevity of the cable lug.

High temperatures can cause the cable lug to expand, resulting in a loose connection, while low temperatures can cause the cable lug to contract and become brittle, leading to a potential crack. Humidity can also affect the performance of the cable lug, as moisture can cause corrosion and reduce conductivity.

When selecting the appropriate cable lug, consider the temperature and humidity levels of the environment in which it will be used. This ensures that the cable lug will perform optimally and safely within the electrical system, even in harsh environmental conditions.

Customizable Options

MOQ:	There are no MOQ limit in first order, and 100pcs in further.
Samples:	We are providing the samples by free, but need pay for the freight charge.
Material design and supply:	We are supplying for LV and MV EPC material in lot many years.

Application Scope of Lugs and Connectors

Residential Wiring

In residential wiring, lugs and connectors are used to connect wires to switches, outlets, and breaker panels. They ensure that electrical connections are secure and that the wiring can handle the required electrical load without issues.

Industrial Applications

In industrial settings, lugs and connectors are used in motor control centers, electrical distribution panels, and heavy machinery. These applications often involve high currents and voltages, making the use of reliable lugs essential for safety and efficiency.

Automotive and Marine Applications

In the automotive and marine industries, lugs and connectors are used to connect battery terminals, starter motors, and other electrical components. The harsh conditions in these environments, including exposure to moisture and vibration, make the use of high-quality lugs crucial.

Renewable Energy Systems

Lugs and connectors are also widely used in renewable energy systems, such as solar panels and wind turbines. These systems require reliable connections to ensure the efficient transfer of energy from the source to the electrical grid or storage systems.

Ordering Process

Buyer sends inquiry --> Buyer receives quotation --> Order confirmation --> Buyer sends deposit --> Seller prepares

Payment Terms

1:	We are accepting T/T and L/C payment terms. And FOB, CIF, CFR.
2:	Sample order: 100% payment before shipment.
3:	Bulk order: 50% deposit balance before shipment.

After-Sales Service

Give a clear answer to the user's complaints within 24 hours.

If necessary, we send technicists to the user's site to solve the problem timely.

Return visit at regular intervals.

Establishing the user's record.

Long warranty period, and whole life service and support.

Providing the latest industrial information.

FAQ

Q: What materials are lugs and connectors made of?

A: Lugs and connectors can be made of various materials, such as copper, aluminum, tin-plated copper, and phenolic or thermoplastic materials for insulation. The choice of material depends on the application, electrical requirements, and environmental conditions.

Q: What are the safety standards for lugs and connectors?

A: Lugs and connectors must meet relevant safety standards and certifications, such as UL and CSA. These standards ensure that the products are safe for use in electrical installations and comply with industry regulations.

Q: What are the benefits of using lugs and connectors?

A: Lugs and connectors offer several benefits, including ease of installation, flexibility in design and application, and improved safety and reliability in electrical installations. They also allow for easy maintenance and repairs.

Q: What are the installation tips for lugs and connectors?

A: Proper installation of lugs and connectors is crucial for ensuring safe and reliable electrical connections. Follow the manufacturer's instructions and safety guidelines, use the correct tools and techniques, and ensure that all connections are tight and secure.

Q: How do I maintain lugs and connectors?

A: Regular maintenance of lugs and connectors is important for ensuring their long-term reliability. Inspect connections regularly for signs of wear, corrosion, or damage, and replace any defective parts as needed. Keep the connections clean and dry to prevent corrosion and short circuits.

Q: Can I use lugs and connectors in wet environments?

A: The suitability of lugs and connectors for use in wet environments depends on the specific product and its ratings. Some products are designed for use in wet or damp locations and have waterproof or weatherproof features. Always check the product specifications and safety standards before use.

Q: What are the applications of lugs and connectors?

A: Lugs and connectors are widely used in electrical installations, including power distribution systems, control panels, motor controls, heating, air conditioning, and refrigeration systems. They are also used in DIY projects and various industrial applications.

We're well-known as one of the leading lugs and connectors manufacturers and suppliers in China. Welcome to buy high quality lugs and connectors at low price from our factory. Contact us for more discount information.
