NX Wedge Clamps（Non-adjustable Type）
NX Series strain clamp is suitable for distribution wire up to 20kv.firstly, fix the aerial insulation aluminum conductor or naked aluminum conductor on the rotate angle or insulator of terminal strain pole, and then fix and tight the aerial conductor.
Description
NX Series strain clamp is suitable for distribution wire up to 20kv.firstly, fix the aerial insulation aluminum conductor or naked aluminum conductor on the rotate angle or insulator of terminal strain pole, and then fix and tight the aerial conductor.
Producing capacity: 100000pcs/month
DKLINE NX wedge clamps
DESCRIPTION
NX Series strain clamp is suitable for distribution wire up to 20kv.firstly, fix the aerial insulation aluminum conductor or naked aluminum conductor on the rotate angle or insulator of terminal strain pole, and then fix and tight the aerial conductor.
DKLINE NX wedge clamps
FEATURES
■ Easy to use.
■ Corrosion resistant.
■ Free sample.
■ Professional technology support.
DKLINE NX wedge clamps
TECHNICAL PARAMETERS
|
Material and Construction |
|
|
Body |
Aluminium |
|
Wedge |
Aluminium |
|
The rest |
H.D.G.Steel |
|
Producing Capacity |
|
|
Producing Capacity |
100000sets per month |
|
USE |
|
|
Scope of use |
6.6-16.0 mm |
DKLINE NX wedge clamps
DATAS AND DIMENSION
|
Catalog No. |
Application of wire diameter |
Main Dimensions |
Specified Failure Load (KN) |
Weight(kg) |
|||
|
C |
M |
L |
R |
||||
|
NX-1 |
6.6-7.8 |
18 |
16 |
150 |
6.0 |
45 |
1.19 |
|
NX-2 |
9.0-11.0 |
20 |
18 |
180 |
7.3 |
88 |
1.76 |
|
NX-3 |
13.0-14.0 |
25 |
24 |
195 |
8.0 |
143 |
3.20 |
|
NX-4 |
15.0-16.0 |
30 |
27 |
220 |
8.0 |
164 |
4.60 |
DKLINE NX wedge clamps
FAQ:
What is the MOQ?
There are no MOQ limit in first order, and 100pcs in further.
Samples providing?
We are providing the samples by free, but need pay for the freight charge.
EPC material design and provide in lot?
Yes, we are supplying for LV and MV EPC material in lot many years.and have strong design team.
OEM available?
Yes, we are providing the anchor clamp as custom requirement.
Complete documents for tender?
Yes, whole set documents ready for submit.
DKLINE NX wedge clamps
ADVANTAGE:
Full set quality control plan to confirm the quality;
ISO 9001, ISO 14001 and ISO 18001 factor;
Low cost low price.
Quick response, fast quotation.
Dependably after-sale service.
Full set documents to submit the tender.
