Hex Bolts
The Hex Bolts, also known as a Hex Bolts, is a fixing tool with a hole in the center and a thread on the inside of the hole, often shared with screws of the same size to fix the relevant joint part.
Description
DKLINE Hex Bolts
DESCRIPTION
Hex Boltss and bolts or screws screwed together to play a fastening role of the parts, all manufacturing machinery must use a component according to the different materials, divided into carbon steel, stainless steel, non-ferrous metals and other major types.
The Hex Boltss are mostly hexagonal, followed by squares.
DKLINE Hex Bolts
Size comparison table
|
Specification |
Thickness |
Opposite angles |
Opposite side |
|
M8 |
6.8 |
14.4 |
13 |
|
M10 |
8.4 |
17.8 |
16 |
|
M12 |
10.8 |
20.0 |
18 |
|
M14 |
12.8 |
23.4 |
21 |
|
M16 |
14.8 |
26.8 |
24 |
|
M18 |
15.8 |
29.6 |
27 |
|
M20 |
18.0 |
33.0 |
30 |
|
M22 |
19.4 |
37.3 |
34 |
|
M24 |
21.5 |
39.6 |
36 |
|
M27 |
23.8 |
45.2 |
41 |
|
M30 |
25.6 |
50.9 |
46 |
|
M33 |
28.7 |
55.4 |
50 |
|
M36 |
31.0 |
60.8 |
55 |
|
M39 |
33.4 |
66.0 |
60 |
|
M42 |
34.0 |
72.3 |
65 |
|
M45 |
36.0 |
79.0 |
70 |
DKLINE Hex Bolts
FAQ:
1.What is the MOQ?
There are no MOQ limit in first order, and 1000pcs in further.
2.Samples providing?
We are providing the samples by free, but need pay for the freight charge.
3.EPC material design and provide in lot?
Yes, we are supplying for LV and MV EPC material in lot many years.and have strong design team.
4.OEM available?
Yes, we are providing the anchor clamp as custom requirement.
5.Complete documents for tender?
Yes, whole set documents ready for submit.
DKLINE Hex Boltsg
ADVANTAGE:
Full set quality control plan to confirm the quality;
ISO 9001, ISO 14001 and ISO 18001 factor;
Low cost low price.
Quick response, fast quotation.
Dependably after-sale service.
Full set documents to submit the tender.
